尺寸表 dimension table 單位Unit：mm
型號(hào) Model |
A |
B |
C |
D |
E |
G |
H |
K |
L |
N |
O |
Z | 氣 源 接 口
Air connection |
DA/SR-45 |
48 |
58 |
65 |
20 |
14 |
Φ36 |
Φ50 |
M5×8 |
150 |
80 |
M6×10 |
14 |
G1/8'' |
DA/SR-52 |
50 |
59 |
74 |
20 |
14 |
Φ36 |
Φ50 |
M5×8 |
150 |
80 |
M6×10 |
14 |
G1/8'' |
DA/SR-63 |
60 |
72 |
88 |
20 |
18 |
Φ50 |
Φ70 |
M6×10 |
173 |
80 |
M8×13 |
18 |
G1/8'' |
DA/SR-75 |
65 |
83 |
100 |
20 |
18 |
Φ50 |
Φ70 |
M6×10 |
187 |
80 |
M8×13 |
18 |
G1/8'' |
DA/SR-83 |
68 |
91 |
110 |
20 |
18 |
Φ50 |
Φ70 |
M6×10 |
214 |
80 |
M8×13 |
21 |
G1/8'' |
DA/SR-92 |
79 |
104 |
120 |
20 |
25 |
Φ50 |
Φ70 |
M6×10 |
265 |
80 |
M8×13 |
21 |
G1/8'' |
DA/SR-105 |
84 |
114 | 132 .5 |
20 |
25 |
Φ70 |
Φ102 |
M8×13 |
276 |
80 |
M10×16 |
26 |
G1/8'' |
DA/SR-125 |
103 |
137 |
160 |
30 |
40 |
Φ70 |
Φ102 |
M8×13 |
306 |
130 |
M10×16 |
26 |
NAMUR G1/4'' |
DA/SR-140 |
107 |
150 |
170 |
30 |
4 |
Φ102 |
Φ125 |
M10×16 |
400 |
130 |
M12×20 |
31 |
NAMUR G1/4'' |
DA/SR-160 |
110 |
172 |
197 |
30 |
40 |
Φ102 |
Φ125 |
M10×16 |
465 |
130 |
M12×20 |
31 |
NAMUR G1/4'' |
DA/SR-190 |
115 |
206 |
226 |
30 |
60 |
Φ140 |
530 |
130 |
M16×20 |
40 |
NAMUR G1/4'' | ||
DA/SR-210 |
135 |
226 |
260 |
30 |
60 |
Φ140 |
536 |
130 |
M16×25 |
40 |
NAMUR G1/4'' | ||
DA/SR-240 |
155 |
256 |
290 |
30 |
60 |
Φ165 |
602 |
130 |
M16×25 |
50 |
NAMUR G1/4'' | ||
DA/SR-270 |
172 |
294 |
320 |
30 |
60 |
Φ165 |
715 |
130 |
M16×25 |
50 |
NAMUR G1/2'' | ||
DA/SR-300 |
196 |
324 |
348 |
30 |
60 |
Φ165 |
742 |
130 |
M16×25 |
60 |
NAMUR G1/2'' | ||
DA/SR-350 | 220 | 380 | 408 | 30 | 60 | Φ165 | 860 | 130 | M16×25 | 60 | NAMUR G1/2'' |
